Piston Valve Suppliers
Piston Valve Suppliers in Pune, Dealers, Distributors & stockiest in Pune
Unison Enterprises is leading Piston Valve Suppliers in Pune, Dealers, Distributors and Stockists in Pune. We possess 15+ years’ of experience and provide precision engineered valves of engineering, long run, and smooth operation and reliable flow control. Our piston valves are high quality, can be used in steam, water, and industrial work, and will last long and maintain minimal maintenance. We have done more than 50k+ works on projects. As we have the ready stock, competitive prices, and prompt delivery, we deliver according to various industry needs in an efficient, consistent way, and to the maximum customer satisfaction.
About Piston Valve
It is a stable flow valve used in controlling the flow of steam, liquids and gases. It has a piston-type sealing system, which guarantees a tight shut-off and a smoother operation during the high pressure and high temperature. A Piston Valve is characterized by long life and low maintenance and is considered to be suitable in the industrial applications that are demanding.
Types of Piston Valve
As Piston Valve Suppliers in Pune, we provide following types of Piston Valve:
-
Based on Pressure / Design
- Balanced Piston Valve: It has pressure-balancing channels designed to decrease the operating torque, which makes it optimal in high-pressure industry use.
- Unbalanced Piston Valve: Fitted in low to medium pressure systems, provides dependable working performance at an easy and affordable design.
-
Based on Function / Structure
- Angle Piston Valve: Pneumatic Angle Type Piston Valve has an angled body design with a high degree of pneumatic actuation to allow rapid and efficient automated flow control.
- Regulating / Throttling Piston Valve: Constructed to have an inclined piston surface to enable fine control of the flow in throttling.
- Normal (On/Off) Piston Valve: Normal flat-bottom piston type employed in pipelines full-flow use or complete shut-off.
-
Based on End Connections
- Screwed Piston Valve: Ideal in small pipelines and lower pressure systems, in which installation and maintenance is easy.
- Flanged Piston Valve: Applicable in high pressure and high temperature, which offer robust and reliable pipe fittings.
- Socket Weld / Butt Weld Piston Valve: Provides leak free, high strength connections in the rigorous industrial setting.
-
Other Variations
- Piston Check Valve (Lift Check Type): Prevents reverse movement by enabling movement of the fluid in a single direction and making the system safe.
- Forged Steel / Cast Steel Piston Valve/ Glandless Piston Valves: Produced with hard materials that would last under pressure, temperature and extreme conditions of operation.
Technical Specifications of Piston Valve
As Piston Valve Dealers in Pune, our valves are available with following technical specifications.
| Parameter | Specification |
|---|---|
| Size Range | ½” to 8” (DN 15 to DN 200) |
| Pressure Ratings | Class 150, 300, 600, 800 / PN 16, PN 40, PN 63 |
| Body Materials | Forged Carbon Steel (ASTM A105), Cast Steel (ASTM A216 WCB), Stainless Steel (ASTM A351 CF8 / CF8M) |
| Internal Components | Stainless Steel Piston (ASTM A276 Type 420 / 316) |
| Sealing Elements | Graphite or PTFE (based on application requirement) |
| End Connections | Screwed (NPT / BSPT), Socket Weld, Flanged (ASME B16.5) |
| Temperature Range | Up to 400°C (depending on packing and sealing material) |
| Design Standards | ASME B16.34, API 598 |
| Operation Type | Manual (Handwheel), Pneumatic, or Hydraulic Actuation |
Features of Piston Valve
As Piston Valve Distributors in Pune, our Industrial Piston Valves are superior to avoid leakage and durable in nature.
- Superior Leak-Tight Sealing
Piston valves are designed to achieve high sealing performance to ensure that leakage is reduced and that they operate safely even in high pressure systems. - Seatless and Glandless Construction
The absence of traditional seats and glands eliminates potential leakage prone areas and limits the amount of maintenance. - High-Strength and Robust Design
They are made to meet the high-pressure and high-temperature requirements and work well in the harsh industrial conditions. A High Pressure Piston Valve is perfect for demanding systems. - Precise Flow Regulation
Linear piston movement gives good and consistent flow control, which can be used in both on/off and throttling. - Easy Maintenance and Durability
Sealing rings are shielded against direct flow erosion, and this enhances the life span of the seal as well as allowing easy internal servicing without the need to remove the pipeline.
Applications of Piston Valve
As Piston Valve Dealers in Pune, we serve various industries for efficient and leak free operations.
- Steam and Heat Management Systems
Steamlok Piston Valve finds extensive application as an isolation valve in steam header, manifolds and thermic fluid systems, where it covers safe and efficient flow of heat. - Chemical and Process Industries
It is used in chemical, petrochemical and refinery environments in applications involving corrosive and abrasive fluids and offers leak free and reliable operation. - Flow and Pressure Regulation
It is fitted in pressure-reducing stations and process lines to have a constant control of high pressure and high-viscosity media. - Power Generation and Utility Services
It is applied in high pressure water systems, steam lines, and HVAC systems to provide reliable operation in the power and utility plants. - Specialized Industrial Operations
It is used in the molding, casting and industrial filtration systems where it is used to provide durability, tight sealing and uniform process efficiency. UKL Piston Valve is preferred in such critical setups.
Why Choose Us as Industrial Piston Valve Suppliers in Pune?
- Extensive Product Availability: As Piston Valve Stockists in Pune, we keep an extensive inventory of piston valves in stock to dispatch quickly and deliver on time when there is an urgent requirement in the industry.
- Assured Quality and Compliance: We are providing valves that are of a proven industry quality that promises reliable performance and extended operational life in essential service.
- Technical Expertise: We help in choosing the right specifications of piston valves in order to provide accurate, application-oriented, and economical solutions.
Unison Enterprises is well-known Piston Valve Suppliers in Pune, Dealers, Distributors and Stockists in Pune. Our mission is to provide quality piston valves that satisfy various needs of industries with quality and consistency. We guarantee product availability, compliance to industry standards, and solution orientation. Through our powerful sourcing network and performance commitment we aim to offer long lasting, efficient and cost effective solutions to our piston valves which will add long term value to any project. Connect With Us to get more information.
FAQ’s
Piston valves are designed to control or isolate the flow of steam, liquid and gases in industrial pipes. It can be used in on/off as well as throttling applications.
The advantages of piston valves are that they have a good sealing, minimal leakage and less maintenance since they are glandless in their design. They work under pressure and conditions of high temperature.
Piston valves are commonly utilized in steam lines, steam headers and thermic fluid systems as they are tight-shutting and durable.
